Gateway LRW Outdoor UG65-EA

Name: Gateway LRW Outdoor UG65-EA
Brand: Thermokon
SKU: 810142

Outdoor LoRaWAN gateway with an external antenna, an integrated network and application server and an MQTT client interface.

Sign in for trade prices

Availability and lead time confirmed on your quote

Part number810142

Quotes answered within 24 hours, no account needed
DHL, under 15 kg £13.50 ex VAT
Technical support from the people who commission it

Specification

Communication

Protocol: LoRaWAN (868 MHz), TCP/IP, MQTT
Interface: RJ45 Ethernet, 10/100 Mbit/s

Electrical

Power supply: 18 to 24 V DC SELV or PoE
Power consumption: 3 W typical at 24 V DC

Environment

Operating temperature: -40 to +70 °C
Humidity: Maximum 90% rH, non-condensing
Protection: IP65 IP rating

Physical

Colour: White
Mounting: Wall or pole
Dimensions: 198 x 45 mm (length x width)
Weight: 230 g

From the manufacturer's datasheet for 810142.

Overview

The UG65-EA is an IP65 outdoor gateway for 868 MHz LoRaWAN sensors. It has a built-in network and application server, so a small LoRaWAN installation needs no cloud service, and an MQTT client sends the data straight to a higher level system. It is set up through a web interface and connects by Ethernet. It can be powered by PoE or from 18 to 24 V, and mounts on a wall or a pole.

Picture coming soon

Thermokon · Gateway · LoRaWAN
