Thermokon · Room sensor · Modbus
NOVOS 3 RS485 Modbus
Room sensor with an ePaper display and colour LED traffic light for temperature, humidity, CO2 and VOC, with an RS485 Modbus RTU output.
Sign in for trade prices
Availability and lead time confirmed on your quote
Part number733496
Datasheet, PDF
- Quotes answered within 24 hours, no account needed
- DHL, under 15 kg £13.50 ex VAT
- Technical support from the people who commission it
Specification
Communication
- Protocol
- Modbus RTU
- Interface
- RS485 Modbus, half duplex, 9600 to 57600 baud, parity none (2 stop bits), even or odd (1 stop bit)
Electrical
- Power supply
- 15 to 35 V DC or 19 to 29 V AC, SELV
- Power consumption
- Typically 0.4 W at 24 V DC, 0.8 VA at 24 V AC
Environment
- Operating temperature
- 0 to +50 °C, humidity up to 85% rH non-condensing
- Protection
- IP20 IP rating
Performance
- Inputs
- 1 input for a floating contact
- Measuring range
- Temperature 0 to +50 °C by default; humidity 0 to 100% rH; CO2 0 to 2000 or 0 to 5000 ppm; VOC mixed gas
- Accuracy
- Temperature ±0.5 K, humidity ±2% between 10 and 90% rH, CO2 ±50 ppm +3% of reading (typical at 21 °C)
- Sensor element
- CO2 with dual channel self calibration; VOC by heated metal oxide semiconductor
Physical
- Housing material
- PC V0
- Colour
- Pure white
- Mounting
- Flush on a 60 mm EU box, or surface mounted flat with adhesive foil or screws
- Dimensions
- 110 x 100 x 23 mm
Part numbers
From the manufacturer's datasheet for NOVOS 3 RS485 Modbus.
Overview
The NOVOS 3 is a room sensor for measuring temperature, humidity, CO2 and mixed gas (VOC), depending on the part. Absolute humidity, enthalpy and dew point are calculated from the humidity reading. It suits schools, offices, hotels and cinemas. An ePaper display shows the values, and an RGB LED gives a traffic light indication when configurable thresholds are passed. Settings are made with the Thermokon NOVOSapp or uConfig, and all values are read over RS485 Modbus RTU. There is one input for a floating contact. The mixed gas sensor responds to volatile organic compounds such as body odour, tobacco smoke and gases given off by furniture, carpets and paint. The base can be mounted and wired separately from the front, in a 60 mm EU box or flat on a wall.
