Thermokon · Room operating unit · LoRaWAN
NOVOS 3 x LoRaWAN
Battery-powered LoRaWAN room unit with an e-paper display, setpoint dial, presence button and temperature and humidity sensors.
Sign in for trade prices
Availability and lead time confirmed on your quote
Part number811217
Datasheet, PDF
- Quotes answered within 24 hours, no account needed
- DHL, under 15 kg £13.50 ex VAT
- Technical support from the people who commission it
Specification
Communication
- Protocol
- LoRaWAN, 868 MHz, bidirectional
Electrical
- Power supply
- 1 x AA battery
Environment
- Operating temperature
- -20 to +70 °C
- Humidity
- Maximum 85% rH, non-condensing
- Protection
- IP20 IP rating
Performance
- Measuring range
- Humidity 0 to 100% rH, non-condensing
- Accuracy
- Temperature +/-0.4 K at 21 °C; humidity +/-2% between 10 and 90% rH
Physical
- Housing material
- PC V0
- Colour
- Pure white
- Mounting
- Flush on a standard EU box of 60 mm diameter, or surface with adhesive foil or screws
- Dimensions
- 110 x 100 x 23 mm
From the manufacturer's datasheet for 811217.
Overview
The NOVOS 3 x LoRaWAN is a room operating unit that sends its readings by LoRaWAN on 868 MHz, so no data cable is needed. It has a setpoint potentiometer, a presence button and an e-paper display of 44 x 24 mm. This version measures temperature and relative humidity. It runs from one AA battery. It can be fitted flush on a standard EU box or surface mounted with the adhesive foil or screws. Setup is by app, uConfig or LoRaWAN downlink.
