Wireless Switch BJ 63x63 EnOcean
Battery-free EnOcean wireless switch for Busch-Jaeger 63 x 63 mm frames, for lights or blinds, two or four channels.
Sign in for trade prices
Availability and lead time confirmed on your quote
Part number730532
Datasheet, PDF
- Quotes answered within 24 hours, no account needed
- DHL, under 15 kg £13.50 ex VAT
- Technical support from the people who commission it
Specification
Communication
- Protocol
- EnOcean, 868 MHz, radio telegram EEP F6-10-00 (RPS)
Electrical
- Power supply
- Maintenance-free electrodynamic energy generator
Environment
- Operating temperature
- -25 to +65 °C
- Humidity
- Max. 85% rH non-condensing
Performance
- Operating force
- 7 N, actuation range 2 mm, more than 50,000 operating cycles
Physical
- Housing material
- PC
- Colour
- Studio white, ivory white or anthracite, by version
- Dimensions
- 73 x 73 x 15 mm
- Mounting
- Surface, flat on the base with adhesive foil or screws
Part numbers
- 7305322-channel light, Studio white
- 7305702-channel light, Ivory white
- 7307542-channel light, Anthracite
- 7305494-channel light, Studio white
- 7305874-channel light, Ivory white
- 7307614-channel light, Anthracite
- 7305562-channel blind, Studio white
- 7305942-channel blind, Ivory white
- 7307782-channel blind, Anthracite
- 7305634-channel blind, Studio white
- 7306004-channel blind, Ivory white
- 7307854-channel blind, Anthracite
From the manufacturer's datasheet for Wireless Switch BJ 63x63 EnOcean.
Overview
This energy-harvesting wireless switch controls lighting or blinds without a battery or wiring. It is made for Busch-Jaeger 63 x 63 mm frame designs, and can be fixed to glass or plasterboard walls with an adhesive pad or screws. It sends an EnOcean telegram as soon as a rocker is pressed. Light versions switch and dim, and blind versions move blinds up and down. It is supplied with two labels showing the transmission ID and adhesive foil for fixing.
